USB出力温湿気圧センサモジュールのサンプルプログラムに関する説明
|
データ構造 | |
| union | __attribute__ |
| union | _REQUEST_TYPE |
| struct | _REQUEST_TYPE::_BM |
| struct | _BM |
| struct | _USB_SETUP_PACKET |
| struct | _USB_DEVICE_DESCRIPTOR |
| struct | _USB_DEVICE_QUALIFIER_DESCRIPTOR |
| struct | _USB_CONFIGURATION_DESCRIPTOR |
| struct | _USB_INTERFACE_DESCRIPTOR |
| struct | _USB_ENDPOINT_DESCRIPTOR |
| struct | _USB_STRING_DESCRIPTOR |
| struct | _USB_COMMON_DESCRIPTOR |
関数 | |
| union _REQUEST_TYPE | __attribute__ ((packed)) REQUEST_TYPE |
| #define REQUEST_CLASS 1 |
| #define REQUEST_DEVICE_TO_HOST 1 |
| #define REQUEST_HOST_TO_DEVICE 0 |
| #define REQUEST_RESERVED 3 |
| #define REQUEST_STANDARD 0 |
| #define REQUEST_TO_DEVICE 0 |
| #define REQUEST_TO_ENDPOINT 2 |
| #define REQUEST_TO_INTERFACE 1 |
| #define REQUEST_TO_OTHER 3 |
| #define REQUEST_VENDOR 2 |
| #define USB_CONFIG_BUS_POWERED 0x80 |
| #define USB_CONFIG_POWER_MA | ( | mA | ) | ((mA)/2) |
| #define USB_CONFIG_POWERED_MASK 0x40 |
| #define USB_CONFIG_REMOTE_WAKEUP 0x20 |
| #define USB_CONFIG_SELF_POWERED 0xC0 |
| #define USB_CONFIGURATION_DESCRIPTOR_TYPE 2 |
| #define USB_DEBUG_DESCRIPTOR_TYPE 10 |
| #define USB_DEVICE_CLASS_AUDIO 0x01 |
| #define USB_DEVICE_CLASS_COMMUNICATIONS 0x02 |
| #define USB_DEVICE_CLASS_HUB 0x09 |
| #define USB_DEVICE_CLASS_HUMAN_INTERFACE 0x03 |
| #define USB_DEVICE_CLASS_MISCELLANEOUS 0xEF |
| #define USB_DEVICE_CLASS_MONITOR 0x04 |
| #define USB_DEVICE_CLASS_PHYSICAL_INTERFACE 0x05 |
| #define USB_DEVICE_CLASS_POWER 0x06 |
| #define USB_DEVICE_CLASS_PRINTER 0x07 |
| #define USB_DEVICE_CLASS_RESERVED 0x00 |
| #define USB_DEVICE_CLASS_STORAGE 0x08 |
| #define USB_DEVICE_CLASS_VENDOR_SPECIFIC 0xFF |
| #define USB_DEVICE_DESCRIPTOR_TYPE 1 |
| #define USB_DEVICE_QUALIFIER_DESCRIPTOR_TYPE 6 |
| #define USB_ENDPOINT_DESCRIPTOR_TYPE 5 |
| #define USB_ENDPOINT_DIRECTION_MASK 0x80 |
| #define USB_ENDPOINT_IN | ( | addr | ) | ((addr) | 0x80) |
| #define USB_ENDPOINT_OUT | ( | addr | ) | ((addr) | 0x00) |
| #define USB_ENDPOINT_SYNC_ADAPTIVE 0x08 |
| #define USB_ENDPOINT_SYNC_ASYNCHRONOUS 0x04 |
| #define USB_ENDPOINT_SYNC_MASK 0x0C |
| #define USB_ENDPOINT_SYNC_NO_SYNCHRONIZATION 0x00 |
| #define USB_ENDPOINT_SYNC_SYNCHRONOUS 0x0C |
| #define USB_ENDPOINT_TYPE_BULK 0x02 |
| #define USB_ENDPOINT_TYPE_CONTROL 0x00 |
| #define USB_ENDPOINT_TYPE_INTERRUPT 0x03 |
| #define USB_ENDPOINT_TYPE_ISOCHRONOUS 0x01 |
| #define USB_ENDPOINT_TYPE_MASK 0x03 |
| #define USB_ENDPOINT_USAGE_DATA 0x00 |
| #define USB_ENDPOINT_USAGE_FEEDBACK 0x10 |
| #define USB_ENDPOINT_USAGE_IMPLICIT_FEEDBACK 0x20 |
| #define USB_ENDPOINT_USAGE_MASK 0x30 |
| #define USB_ENDPOINT_USAGE_RESERVED 0x30 |
| #define USB_FEATURE_ENDPOINT_STALL 0 |
| #define USB_FEATURE_REMOTE_WAKEUP 1 |
| #define USB_GETSTATUS_ENDPOINT_STALL 0x01 |
| #define USB_GETSTATUS_REMOTE_WAKEUP 0x02 |
| #define USB_GETSTATUS_SELF_POWERED 0x01 |
| #define USB_INTERFACE_ASSOCIATION_DESCRIPTOR_TYPE 11 |
| #define USB_INTERFACE_DESCRIPTOR_TYPE 4 |
| #define USB_INTERFACE_POWER_DESCRIPTOR_TYPE 8 |
| #define USB_OTG_DESCRIPTOR_TYPE 9 |
| #define USB_OTHER_SPEED_CONFIG_DESCRIPTOR_TYPE 7 |
| #define USB_REQUEST_CLEAR_FEATURE 1 |
| #define USB_REQUEST_GET_CONFIGURATION 8 |
| #define USB_REQUEST_GET_DESCRIPTOR 6 |
| #define USB_REQUEST_GET_INTERFACE 10 |
| #define USB_REQUEST_GET_STATUS 0 |
| #define USB_REQUEST_SET_ADDRESS 5 |
| #define USB_REQUEST_SET_CONFIGURATION 9 |
| #define USB_REQUEST_SET_DESCRIPTOR 7 |
| #define USB_REQUEST_SET_FEATURE 3 |
| #define USB_REQUEST_SET_INTERFACE 11 |
| #define USB_REQUEST_SYNC_FRAME 12 |
| #define USB_STRING_DESCRIPTOR_TYPE 3 |
| union _REQUEST_TYPE __attribute__ | ( | (packed) | ) |
| uint8_t B |
| uint8_t bAlternateSetting |
| uint16_t bcdDevice |
| uint16_t bcdUSB |
| uint8_t bConfigurationValue |
| uint8_t bDescriptorType |
| uint8_t bDeviceClass |
| uint8_t bDeviceProtocol |
| uint8_t bDeviceSubClass |
| uint8_t bEndpointAddress |
| uint8_t bInterfaceClass |
| uint8_t bInterfaceNumber |
| uint8_t bInterfaceProtocol |
| uint8_t bInterfaceSubClass |
| uint8_t bInterval |
| uint8_t bLength |
| uint8_t bmAttributes |
| uint8_t bMaxPacketSize0 |
| uint8_t bMaxPower |
| REQUEST_TYPE bmRequestType |
| uint8_t bNumConfigurations |
| uint8_t bNumEndpoints |
| uint8_t bNumInterfaces |
| uint8_t bRequest |
| uint8_t bReserved |
| uint16_t bString |
| uint8_t Dir |
| uint8_t H |
| uint8_t iConfiguration |
| uint16_t idProduct |
| uint16_t idVendor |
| uint8_t iInterface |
| uint8_t iManufacturer |
| uint8_t iProduct |
| uint8_t iSerialNumber |
| uint8_t L |
| uint8_t Recipient |
| uint8_t Type |
| WORD_BYTE wIndex |
| uint16_t wLength |
| uint16_t wMaxPacketSize |
| uint16_t wTotalLength |
| WORD_BYTE wValue |
